York E*BD-(T - Manual

246819-BTG-H-0208
FOR DISTRIBUTION USE ONLY - NOT TO BE USED AT POINT OF RETAIL SALE
SPLIT-SYSTEM HEAT PUMPS
13 SEER – R-22
MODELS:
E*BD-F018 THRU 060
(1.5 THRU 5 NOMINAL TONS, 1 PHASE)
E*BD-(T,W)036 THRU 060
(2.5 THRU 5 NOMINAL TONS, 3 PHASE)
Due to continuous product improvement, specifications
are subject to change without notice.
Visit us on the web at www.york.com
Additional rating information can be found at
www.ahridirectory.org
LISTED
ISO 9001
Certified Quality
Management System
TECHNICAL
GUIDE TECHNICAL
GUIDE DESCRIPTION
The 13 SEER series heat pumps are designed for use with a
variety of UPG evaporator sections to suit any application
need. A full line of matching Add-On Coils are available for
use with upflow, downflow or horizontal furnaces. Matching
Air Handlers are also available for upflow, downflow or hori-
zontal installation to provide a complete system. Electric heat
may be installed in air handlers. All units are factory charged
to assure easy installation.
WARRANTY
Single Phase Units:
5-year limited parts warranty.
5-year limited compressor warranty.
Three Phase Units:
1-year limited parts warranty.
5-year limited compressor warranty.
FEATURES
• DURABLE CONSTRUCTION - The outdoor unit is con-
structed of pre-painted steel that offers tough protection
against corrosion and resists fading when exposed to sun-
light. Drain holes are incorporated into the base pan to per-
mit free drainage of moisture.
• QUALITY COILS - The coil is constructed of enhanced
copper tube and aluminum fins.
• COIL PROTECTION - Coils are protected from damage by
a polymer mesh applied between the coil face, and a PVC
coated steel coil guard.
• PROTECTED COMPRESSOR - The hermetic compressor
is internally protected against high pressure and tempera-
ture by the simultaneous operation of a high pressure relief
valve and temperature sensors which stop the compressor
if operating temperatures go too high. Both protectors
reset automatically. A discharge line solid core filter drier
further protects the compressor.
• Complete System Control – These heat pumps utilize
the unique microprocessor defrost control system to pro-
vide optimal comfort and to monitor the overall system for
reliable operation. The defrost control system continuously
monitors the space environment to maintain optimum effi-
ciency. It initiates defrost only when necessary to further
reduce heating costs and improve reliability. In the event
improper operating conditions occur, the control will auto-
matically shut the system down to extend the life of the
heat pump. Rapid cycling is prevented by use of an inter-
nal anti-recycle timer.
• LOW OPERATING SOUND LEVEL - The compressor is
mounted on rubber isolators to reduce operating sounds.
The slow moving condenser fan keeps air turbulence and
sound to a low level.
• EASY ACCESS - Removable panel affords accessibility to
the electrical box.
• FULLY CHARGED AND FACTORY WIRED - to simply
installation and reduce labor costs. Only power supply and
control wiring and refrigerant lines must be connected. All
models are sweat connect with reusable service valves.
• Factory tested - to verify system operation and control
functioning before shipment.
• U.L. and C.U.L. listed - approved for outdoor application.
Certified in accordance with the Unitary Small Equipment cer-
tification program, which is based on ARI Standard 210/240.
