Mounting
975-0239-01-01 4–7
5. Insert two screws in the two mounting holes provided to secure the unit to the wall.
6. Provide strain-relief clamps or conduit to prevent damage to the circuit board and
terminal block from pulling on the wires.
Figure 4-5 Mounting the XW Solar Charge Controller
xantrex
Solar Charge Controller
Secure with two more screws.
Place keyhole
slot over the
mounting screw.
¼"
