Xerox X2 User Manual
Page 24
140 micron Pressure Sensitive Vinyl
13
Description
This is a general-purpose, calendered self-adhesive white vinyl – pressure sensitive – that will
adhere to a wide variety of smooth substrates with flat or gently curved surfaces using only the
slight pressure of a hand or small tool (such as a squeegee). This PSV has a medium tack adhesive
that enables good adhesion in service but will enable complete removal from substrates without the
use of chemicals or heat. It is designed for use in all indoor, and most outdoor, PSV applications
when properly constructed with an over-laminate.
The in receiver coating gives a bright white imaging surface with a good degree of water and scratch
resistance, although lamination is recommended for prints requiring satin, high gloss or other
finishes and/or prints requiring protection from dirt, abrasion or UV, for greater general durability.
This media is suitable for pressure (cold) laminates but not for thermal (hot-melt) laminates.
Applications
For all indoor and some outdoor applications where the printed image is needed to adhere to a
smooth, flat or slightly curved surface: General signage, retail and event promotions, trade show
displays, galleries, museums, hallways, showrooms, markets, retail merchandising and display.
Physical Characteristics
Base Weight
290 g/m
2
Indoor Laminated
2 years
Total Calliper
275 microns
Indoor Unlaminated
6 months
Vinyl Calliper
140 microns
Outdoor Laminated
1 year
Opacity
98%
Outdoor Unlaminated
2 months
Brightness
118
Durability
Adhesive Clear,
removable,
acrylic , pressure-sensitive
Release Liner
Coated paper 120g/m
2
Min. Surface / Ambient Air Application Temp. 10° C
Application Surface
Flat or slightly curved
Dimensions
Code
Length
023R02405
54”
1372mm
20m
023R02404
42"
1067mm
20m
023R02403
36”
914mm
20m
Width
Compatibility
Xerox X2
Xerox Xpress
Seiko IP4XXX
Operating Instructions
• Store in a cool, dry environment, free from direct sunlight, within temperatures of 10-35
o
C and
non-condensing relative humidity of 30-70%. Store the product in its original carton and
wrapper to protect from dust and moisture. Shelf life is 12 months if kept in original packaging.
• Ensure that roll ends are protected and that the edges of the media are not damaged. If the
media edges are not flat this can result in damage to the printer.
• Keep the image surface dry and free of grease, oil, silicones and dirt.
• Print within the temperature range 18-30˚C and relative humidity of 40-60%.
• Clean and prepare substrates following instructions detailed elsewhere in this guide
• Freshly lacquered or painted surfaces should be allowed to dry or cure completely before self-
adhesive vinyl is applied. Test compatibility of surfaces, paints or lacquers prior to application.
• This media is suitable for pressure (cold) laminates but not thermal (hot-melt) laminates.
www.xerox.com/iccprofiles.com
24
