Zebra S400 & S600 User’s Guide 41
0HGLD 5HVW 3RVLWLRQ $GMXVWPHQW
This procedure sets the end-of-label position relative to the Tear-Off plate
or cutter. Adjust this if your label is not being torn or cut at the correct
point.
1. Briefly press the MODE button twice. The PAUSE and POSITION
LEDs turn on.
2. Press UP (FEED) or DOWN (CANCEL) to adjust the current setting.
3. Briefly press the MODE button twice. The MODE LEDs flash on and
off to indicate that the settings have been saved in memory.
4. Press PAUSE to exit the pause mode. The PAUSE LED turns off.
7RS RI WKH /DEHO 3RVLWLRQ $GMXVWPHQW
This procedure positions the printing on the label relative to the top edge
of the label. Adjust this if your printing is too close or too far away from
the top or bottom edge of the label.
1. Briefly press the MODE button twice, then press and hold it for about
five seconds until the lights change. The PAUSE, DARKEN, and
CALIBRATE LEDs turn on.
2. Press UP (FEED) or DOWN (CANCEL) to adjust the current setting.
3. Briefly press the MODE button twice. The MODE LEDs flash on and
off to indicate that the settings have been saved in memory.
4. Press PAUSE to exit the pause mode. The PAUSE LED turns off.
0HGLD 6HQVRU 3RVLWLRQ $GMXVWPHQW
Please see “Adjusting the Media Sensor” on page 18 to adjust the media
sensor position.
5LEERQ 6XSSO\ 6SLQGOH $GMXVWPHQW
Please see page 15 for the ribbon supply spindle adjustment procedure.
