DOCUCOLOR 12 USER GUIDE 4–17 BASIC COPYING
1
2
3
4
5
6
7
Independent X - Y%
Select the Independent X - Y% option to copy the
image at different, independent magnifications
from 25% to 400% for the X and Y directions.
For example, you can enlarge the image to 129%
in the X direction and reduce it to 64% in the Y
direction.
Selecting the Independent X - Y% option on the
Reduce/Enlarge screen displays an additional
screen. This screen, illustrated in Figure 18,
enables you to select variable reduction/
enlargement options:
•
Variable%
•
Auto%
NOTE:
•
The Auto% option is applied only to standard
size documents.
•
The X and Y directions are always determined
in reference to the registration arrow, located
around the Document Glass, Figure 19. The
X direction is always along the long edge of
the Document Glass, and the Y direction is
along the short edge of the Document Glass.
The X and Y direction references on the
Document Glass remain the same, regardless
of the document orientation (long edge
registration or short edge registration).
All of the Independent X-Y options require you
to enter the original orientation that most
closely resembles how the document is
placed on the Document Glass.
Figure 18: Independent X - Y% Options for
Reduce/Enlarge
Figure 19: The X and Y Directions on the
Document Glass
X Direction
Y Direction
