York H*RC018 THRU 060 - Manual (Page 3)

036-21137-003 Rev. A (1102)
Unitary Products Group 3
Additional R-22 Charge / Orifice Size for Various Matched Systems - 1 Phase
Outdoor Unit H2RC018S06 H2RC024S06 H2RC030S06 H2RC036S06 H2RC042S06 H2RC048S06 H3RC060S06
Unit Orifice (s) 1 53 59 63 73 78 87 –
Factory R-22 Charge, lbs-oz. 4 - 9 4 - 7 5 - 8 5 - 3 6 - 13 7 - 7 9 - 0
Indoor Coil Coil Orifice Orifice or TXV Kit 2 - Additional Charge, Oz. 3
G2FD024S(H)14,17 61
53 + 3 59 + 3 – – – – –
701 + 3 701 + 3 – – – – –
G2FD030S(H)17 65
53 + 6 59 + 6 63 + 4 – – – –
701 + 6 701 + 6 701 + 4 – – – –
G2FD035S(H)14 65
53 + 6 59 + 6 63 + 4 73 + 0 – – –
701 + 6 701 + 6 701 + 4 702 + 0 – – –
G2FD036S(H)17 75
– 59 + 10 63 + 8 73 + 6 – – –
– 701 + 10 701 + 8 702 + 6 – – –
G2FD036S(H)21 75
– – 63 + 11 73 + 8 – – –
– – 701 + 11 702 + 8 – – –
G2FD042S(H)21 78
– – 63 + 14 73 + 12 78 + 0 – –
– – 701 + 14 702 + 12 702 + 0 – –
G2FD046S(H)17 78
– – 63 + 16 73 + 12 78 + 0 87 + 0 –
– – 701 + 16 702 + 12 702 + 0 703 + 0 –
G2FD048S(H)21,24 84
– – – 73 + 16 78 + 10 87 + 11 –
– – – 702 + 16 702 + 10 703 + 11 –
G2FD060S(H)24 90
– – – – – 87 + 15 –
– – – – – 703 + 15 703 + 20
G2FD061H24 90
– – – – – 87 + 19 –
– – – – – 703 + 19 703 + 25
G1HD024 59
53 + 5 59 + 4 – – – – –
701 + 5 701 + 4 – – – – –
G1HD036 69
– 59 + 13 63 + 11 73 + 7 – – –
– 701 + 13 701 + 11 702 + 7 – – –
G1HD048 81
– – – 73 + 13 78 + 3 87 + 4 –
– – – 702 + 13 702 + 3 703 + 4 –
G1HD060 93
– – – – – 87 + 12 –
– – – – – 703 + 12 703 + 20
G1FA/G1UA024S14,17 59
53 + 0 59 + 0 – – – – –
701 + 0 701 + 0 – – – –
G1FA/G1UA030S14 65
– 59 + 3 63 + 0 – – – –
– 701 + 3 701 + 0 – – – –
G1FA/G1UA036S14 73
– 59 + 8 63 + 6 73 + 3 – – –
– 701 + 8 701 + 6 702 + 3 – – –
G1FA/G1UA036S17,21 73
– 59 + 6 63 + 4 73 + 0 – – –
– 701 + 6 701 + 4 702 + 0 – – –
G1FA/G1UA048S17 84
– – 63 + 16 73 + 13 78 + 0 87 + 0 –
– – 701 + 16 702 + 13 702 + 0 703 + 0 –
G1FA/G1UA048S21 84
– – 63 + 18 73 + 9 78 + 7 87 + 8 –
– – 701 + 18 702 + 9 702 + 7 703 + 8 –
G1FA/G1UA060S21,24 90
– – – – 78 + 16 87 + 15 –
– – – – 702 + 16 703 + 15 703 + 20
G1NA030S17K 63
53 + 6 59 + 6 63 + 4 – – – –
701 + 6 701 + 6 701 + 4 – – – –
G1NA030S21M 78
53 + 6 59 + 6 63 + 4 – – – –
701 + 6 701 + 6 701 + 4 – – – –
G1NA036S17L 63
– – 63 + 15 73 + 12 – – –
– – 701 + 15 702 + 12 – – –
G1NA048S21D 78
– – – 73 + 12 78 + 0 87 + 0 –
– – – 702 + 12 702 + 0 703 + 0 –
G1NA048S24P 63
– – – 73 + 13 78 + 2 87 + 1 –
– – – 702 + 13 702 + 2 703 + 1 –
