5 Specifications
Note: Your printer may not have all of the options described in these specifications.
General Specifications
Height 13" 330mm
Width 8.25" 209.6mm
Depth 17" 431.8mm
Weight (option-dependent) 17.25 lbs 72.21 kg
Electrical 110 or 220 VAC +10%/ − 15%, 48-62 Hz
5 Amps @ 110V, 3 Amps @ 220V
Built to CISPR 22B, UL 1950, CSA 950, IEC 950, 801-2,-3, and -4 standards;
Complies with FCC class “A” and Canadian Doc. class “A” rules;
Carries the CE mark of compliance
Temperature Operating 40 to 105° F 5 to 40° C
Storage -40 to 140° F -20 to 60° C
Relative humidity 5 to 85%, non-condensing
Communications interface RS-232 Serial Data Interface; 110 - 19,200 Baud; Parity, Bits/Char. and
XON-XOFF or DTR Handshake Protocols - all switch selectable
8-Bit Parallel Data Interface (S-500 only)
Error Detection CRC Protocol
Printing Specifications
Printing Specifications Stripe S-300 Printer Stripe S-500 Printer Stripe S-500 Printer
with Optional 6 Dots
per mm Printhead
Resolution 203.2 dots per inch (8 dots per mm) 152.4 dots per inch
(6 dots per mm)
Dot size (square) 0.00492" (0.125 mm) 0.00656" (0.167 mm)
Maximum print width 4.09" (104 mm)
Print
length
Minimum 0.00492" (0.125 mm)
Maximum Standard memory 6" (152 mm) 15" (381 mm) 26" (660 mm)
With additional
memory
18" (457 mm)
(256 KB expansion)
39" (991 mm)
(512 KB expansion)
39" (991 mm)
(512 KB expansion)
Bar code modulus (“X”) dimension 5 mil to 55 mil 6.6 mil to 72 mil
Programmable constant printing
speeds
2" (50.8 mm) 2" ( 50.8 mm)
3" ( 76.2 mm)
4" (101.6 mm)
5" (127.0 mm)
6" (152.4 mm)
Thin film printhead with Energy Control
#
45
