Chapter 12 - Status Registers & Result Codes
12-11
ATV0
ATV1
X0
X1
X2
X3
X4
X5
X6
X7
34
CONNECT 41600
%
%
%
%
@
36
CONNECT 24960
%
%
%
%
@
37
CONNECT 20800
%
%
%
%
@
39
CONNECT 28800
%
%
%
%
@
$
#
40
CONNECT 26400
%
%
%
%
@
$
#
41
CONNECT 24000
%
%
%
%
@
$
#
42
CONNECT 21600
%
%
%
%
@
$
#
*
Use S42.6 to disable 'RINGING' result code
**
When more than one type of Distinctive Ring is turned on (S40b3-6) ‘RING
n’ will be reported, n=Ring Type # (1-4)
Result Code Chart Symbol Reference:
V
Supported
%
Reports the DTE Speed as:
@
CONNECT DTE_Speed/Protocol DCE_Speed/Error_Control
†
Example:
CONNECT 38400/V.32bis 14400/V.42bis
$
Example: CONNECT 14400/ARQ
#
CONNECT DCE _Speed/Error_Code/Error_Control
†
Example: CONNECT 14400/ARQ/ MNP5
†
Data compression included. 'SREJ' is appended if a V.42 connection with selective
reject is established.
Result Code Field Descriptions
Field Name
Possible Values
Error_Code
NONE, ARQ
Error_Control
LAPM, V42
(This field will not show if no error control is negotiated)
Data_Compression
V42b
DCE_Speed
All possible DCE speeds supported
DTE_Speed
All possible DTE speeds supported
Connect Strings for Error Corrected Connections
To enable the following numerical (ATV0) and verbose (ATV1) result codes when an
error corrected connection is made, set S35 bit 7 to 1.(ATS35.7=1)
Numerical V0
Verbose V1
Numerical V0
Verbose V1
50
CONNECT
57
CONNECT 14400
51
CONNECT 1200
58
CONNECT 16800
52
CONNECT 2400
59
CONNECT 19200
53
CONNECT 4800
60
CONNECT 21600
54
CONNECT 7200
61
CONNECT 24000
55
CONNECT 9600
62
CONNECT 26400
56
CONNECT 12000
63
CONNECT 28800
