Chapter 12 - Status Registers & Result Codes
12-2
Command
bit
dec
hex
Function and description
Ref.
8
8
4-wire leased line - if available
&L2
5,4
0
0
Internal clock (Default)
&X0
16
10
External clock
&X1
32
20
Remote clock
&X2
7,6
0
0
Asynchronous data with buffering (Default)
&M0
64
40
Asynchronous command, synchronous data
&M1
128
80
Direct asynchronous, no data buffering
&M2
192
C0
Synchronous
&M3
S15=
bit
dec
hex
Bit-mapped register
+130
0,1
0
0
Even parity
1
1
Odd parity
2
2 *
No parity
2
0
0 *
1 stop bit
4
4
2 stop bits
4,3
0
0 *
10 bit character length
*C0
8
8
11 bit character length
*C1
16
10
9 bit character length
*C2
24
18
8 bit character length
*C3
7-5
0
0
Profile 0 as active settings after power on
Z0
32
20
Profile 1 as active settings after power on
Z1
64
40
Profile 2 as active settings after power on
Z2
96
60
Profile 3 as active settings after power on
Z3
128
80 *
Factory default as active settings after power
on
Z4
S16=
dec
hex
Test status register
+000
0
0
No test in progress
&T0
1
1
Loop-back test in progress
&T1
3
3
Local Digital Loop-back test in process
&T3
6
6
Remote Digital Loop-back test in process
&T6
7
7
Remote Digital Loop-back with self-test in
process
&T7
8
8
Analog Loop-back with self test in progress
&T8
S17=
bit
dec
hex
Bit-mapped register
+018
4-1
0-30
0-1E
Set leased line transmit power level from 0 to -
15 dBm. (See also S35b3) (Default *P9)
*Pn
5
0
0
Normal dial (Default)
D
32
20
Reverse dial, go on-line in answer mode.
DR
7,6
0
0
AT Commands set (Default)
*I0
64
40
V.25bis command set
*I1
128
80
Dumb mode (no command accepted)
*I2
S18=
dec
hex
Force modem or TA to fix baud rate when idle +000
0 *
0
Disable fixed baud function
n+1
Enable baud rate fixing at idle, n=0-15 baud
rate value settings (n) the same as S20 value
S19=
dec
hex
Modem connection mode, same
+000/&
Nn
0-73
0-49
setting value as 'AT&Nn' command
