2750 op#2 R3.doc 10-02 Page 2-10
4. Remove the document from the accordion folder in-feed rollers. If that isn’t possible, see “Accordion
Folder” below. Lower and lock the bridge.
TOWER
To clear jams in the tower, use the recessed center handle to open the tower cover, then swing the inner
sheet metal components GENTLY up to expose the hand feed and stacking paper paths. Clear all paths
of paper, then close the tower to restart the folder.
Raising the bridge
The bridge is a precisely manufactured
assembly. DO NOT use it as a seat or step,
and DO NOT slam the bridge into its down or
up positions! When returning the bridge to the
down position, allow the bridge to engage
gently the fixed stops inside the tower, then
turn the knurled knob to lock the bridge in
place.
Access to the tower
The entire upper section of the tower hinges
open for access. Please handle it with care.
DO NOT allow it to slam open or closed!
