Page 63: Appendix b

SP605 Hardware User Guide
63
UG526 (v1.8) September 24, 2012
Appendix B
Default Jumper and Switch Settings
shows the default switch settings and
shows the default
jumper settings for the SP605.
Table B-33:
Default Switch Settings
REFDES
Function/Type
Default
SW2
Board power slide-switch
off
SW1
FPGA mode 2-pole DIP switch, Slave SelectMAP
default selects System ACE CF configuration
2
M1 = 1
on
1
M0 = 0
off
S1
System ACE CF configuration and image select
4-pole DIP switch
4
SysAce Mode = 1
on
3
SysAce CFGAddr2 = 0
off
2
SysAce CFGAddr1 = 0
off
1
SysAce CFGAddr0 = 0
off
S2
User GPIO 4-pole DIP switch
4
off
3
off
2
off
1
off
