Chapter 1: SP605 Evaluation Board
I/O Voltage Rails
There are four available banks on the XC6SLX45T-3FGG484 device. Banks 0, 1, and 2 are
connected for 2.5V I/O. Bank 3 is used for the 1.5V DDR3 component memory interface of
Spartan-6 FPGA’s hard memory controller. The voltage applied to the FPGA I/O banks
used by the SP605 board is summarized in
References
See the Xilinx Spartan-6 FPGA documentation for more information at
.
2. 128 MB DDR3 Component Memory
There are 128 MB of DDR3 memory available on the SP605 board. A 1-Gb Micron
MT41J64M16LA-187E (96-ball) DDR3 memory component is accessible through Bank 3 of
the LX45T device. The Spartan-6 FPGA hard memory controller is used for data transfer
across the DDR3 memory interface’s 16-bit data path using SSTL15 signaling. The SP605
board supports the “standard” VCCINT setting of 1.20V ± 5%. This setting provides
memory controller block (MCB) performance of 667 MT/s for DDR3 memory. Signal
integrity is maintained through DDR3 resistor terminations and memory on-die
terminations (ODT), as shown in
and
Table 1-2:
I/O Voltage Rail of FPGA Banks
FPGA Bank
I/O Voltage Rail
0
2.5V
1
2.5V
2
2.5V
3
1.5V
Table 1-3:
Termination Resistor Requirements
Signal Name
Board Termination
On-Die Termination
MEM1_A[14:0]
49.9
Ω to V
TT
–
MEM1_BA[2:0]
49.9
Ω to V
TT
–
MEM1_RAS_N
49.9
Ω to V
TT
–
MEM1_CAS_N
49.9
Ω to V
TT
–
MEM1_WE_N
49.9
Ω to V
TT
–
MEM1_CS_N
100
Ω to GND
–
MEM1_CKE
4.7 K
Ω to GND
–
MEM1_ODT
4.7 K
Ω to GND
–
MEM1_DQ[15:0]
–
ODT
MEM1_UDQS[P,N], MEM1_LDQS[P,N]
–
ODT
MEM1_UDM, MEM1_LDM
–
ODT
