Part identification chart – Weider club 4870 WESY3906.0 User Manual
Page 5
M6 Washer (90)
M8 Nylon Locknut (101)
M10 Washer (108)
M10 Nylon Locknut (84)
M6 Nylon Locknut (103)
M4 x 16mm
Self-tapping
Screw (100)
M8 x 25mm
Shoulder Bolt (92)
2 1/4" Bolt Set (86)
M10 x 40mm Bolt (104)
M10 x 35mm Screw (89)
M10 x 50mm Bolt (105)
M10 x 45mm Bolt (95)
M
PART IDENTIFICATION CHART
Refer to the drawings below and on page 6 to identify small parts used in assembly. The number in parentheses
by each drawing is the key number of the part, from the PART LIST on page 32 of this manual.
Note: Some
small parts may have been pre-attached. If a part is not in the parts bag, check to see if it has been pre-
attached.
5
