10
8. Attach the Left Seat Upright (14) to the Left Base
(2) with the indicated M10 x 80mm Carriage Bolts
(88) and two M10 Nylon Locknuts (84).
7. Attach the Left Upright (8) to the Left Base (2)
with two M10 x 90mm Bolts (102) and two M10
Nylon Locknuts (84).
Do not tighten the Nylon
Locknuts yet.
7
8
102
2
84
8
2
88
84
14
84
9. Attach the Right Top Frame (3) to the Center
Upright (9) with two M10 x 70mm Bolts (57), two
M10 Washers (108), and an M10 Nylon Locknut
(84).
Do not tighten the Bolts yet.
Attach the Right Top Frame (3) to the Right
Upright (7) with two M10 x 90mm Bolts (102) and
two M10 Nylon Locknuts (84).
Do not tighten the
Nylon Locknuts yet.
84
57
84
7
9
102
108
3
9
