Windsor Carpet Maintainer IMIE17 10066550 - Manual (Page 47)

WIRING-230V DELUXE
86269870 04/14/08 5-32
REF PART NO. PRV NO. QTY DESCRIPTION
SERIAL NO.
FROM
NOTES:
1 86218880 41594 1 HARNESS, MAIN, 230VAC, IMIE
2 86226220 880462 1 WIRE, 10” BLK/18 76040 X 76040
3 86226260 880468 1 WIRE, ORG/18 76040 X 76040
4 86226270 880469 1 WIRE, 18” ORG/18 76040 X 76040
5 86226280 880471 1 WIRE, 9” BLK/18 76040 X 76040
6 86302450 - 1 ASM, FILTER, EMI MAIN
7 86310150 - 1 ASSY, FILTER, EMI MTR
8 OPEN - - -
9 86306770 - 1
HARNESS, PUMP HOUSING, DLX
230
10 86013090 - 1 WIRE, 9.5” GRN/18
11 86306760 - 1 WIRE, 4 W/WIRE JOINT, BLK
12 86013950 - 1 WIRE ASSY, W/2 PIN CONN, DLX
