Windsor Carpet Maintainer IMIE17 10066550 - Manual (Page 39)

SOLUTION TANK - DELUXE
86269870 04/14/08 5-24
REF PART NO. PRV NO. QTY DESCRIPTION
SERIAL NO.
FROM
NOTES:
1 86299710 - 1 CPLR, BODY, 1/4" BARB, GRY
2 86299720 - 1 CPLR, PNL MNT, 1/4" BARB, GRY
3 86012500 - 1 SEAL, COUPLER, EPDM RUBBER
4 86219230 41581 1 HOSE, SUCTION, TANK, DELUXE
5 86225300 75489 1 TANK, DLX (MACH)
6 86013850 - 3 WASHER, M6, FNDR, SS
7 86172820 70883 5 SCR, M5 X 20, PHMS, ISO7045, SST
8 86012570 - 1 STRAP, CHEMICAL BOTTLES, DLX
9 86012940 - 5 SCR, KA40X35, PT OVL, PL
10 86216780 27909 2 CLAMP, TUBE 1/4"
11 86172870 70898 2 SCR, M4X14 PHMS, SST
12 86217560 41577 1 COVER, PUMP, TOP, DELUXE
13 86012520 - 2 GASKET, SEAL, NEOPRENE, RBR
14A 86201120 250-78A 1 PUMP, 220/240V 50HZ FLOJET 230V
14B 86201110 250-78 1 PUMP, 110/120 60HZ FLOJET 110V
15 86240520 40097 4 HOSEBARB, 1/8MPT X 1/4 90D
16 86172990 70913 3 SCR, M6 X 12 BHCS, ISO 7380, SS
17 OPEN - - -
18 86217550 41576 1 COVER, PUMP, DELUXE
19 86012530 - 2 GROMMET, 9.3MM ID X 23MM OD
20 86012560 - 1 STRAINER, 1/8 NPT, 80 MESH
21 86233090 20016 4 CLAMP, 1/4 ID HOSE
22 86012970 - 2 WASHER, M5, FNDR, SS
23 86006770 70323 1 SCR, 10-32 X 1/4 PHTR PLTD
24 86224970 730382 1 STRAP, SPRAYER HOLD DOWN
25 86012470 - 1 CAP, 2-1/4, POWER GRIP
26 86290030 - 1 HOSE, 3/8OD X 1/4ID URTHN X 30”
27 86290010 - 1 HOSE, 3/8OD X 1/4ID URTHN X 8”
28 86290020 - 1 HOSE, 3/8OD X 1/4ID URTHN X 27”
29 86299320 - 1 LABEL, GROUND SYMBOL
30 86225320 78601 1 TIE-CABLE, NYLON
31 86010640 87016 1 WASHER, #10 LOCK EXT STAR SS
