ELECTRICAL-120V
86269870 08/20/08 5-8
REF PART NO. PRV NO. QTY DESCRIPTION
SERIAL NO.
FROM
NOTES:
1 86002010 14942 1 BOOT, 3/8 CIRCUIT BREAKER
2 86217120 23729 1 CORD SET, 18/3 X 40FT SJT
3 86214770 38370 1 ASM RED BUTTON W/BEZEL
4 86214780 38371 1 ASM GREEN BUTTON W/BEZEL
5 86225070 38372 2 SWITCH, ITW, MICRO
6 86198450 20005 2 CLAMP, 5/16 NYLON
7 86225320 78601 1 TIE, CABLE NYLON
8 86173100 70935 4 SCR, M3X6, BSHCS, SST
9 86291470 - 1 BRKT, MTR BRKT, SWITCH, CVR
10 86291490 - 1 COVER, SWITCH, BRKT
11 86291880 - 2 SCR, M3X12, BSHCS, SST
12 86216800 20110 1 CLIP, WIRE
13 86277600 70882 1 SCR, M4X20, PPHMS, SST
14 86215670 140839 1 BREAKER, 8A VDE CIRCUIT
15 86172880 70901 5 SCR, M4X6, BSHCS, SST
16 86173200 70950 1 SCR, M4X16, BSHCS, SST
17 86225850 87517 2 WASHER, M3, FL, ISO7089, SST
18 86223400 67516 1 RELAY, 15A 120VAC MINI
19 86223390 67488 1 RECTIFIER, 50A 600V BRIDGE
20 86173210 70951 4 SCR, M5X10, BSHCS, SST
21 86291860 - 1 SWITCH, 125VAC SP NC ROLLER
22 86222670 05248 1 PLATE, BASE, ELECTRICAL MTG
23 86216740 20040 2 CLAMP, 17,7 NYLON
24 OPEN - - -
25 86013570 - 2 SWITCH, PUSHBUTTON, BL, DLX DELUXE ONLY
26 86299320 - 2 LABEL, GROUND SYMBOL
27 86313930 - 4 SWITCH, W/COUPLER, N.C. *(1)
BASIC (QTY 1)
DELUXE (QTY 2)
28 86295190 - 2 ASM, BUTTON, BLUE, W/BEZEL *(1) DELUXE ONLY
29 86295150 - 1 ASM, BUTTON, RED, W/BEZEL *(1)
30 86295180 - 1 ASM, BUTTON, GREEN, W/BEZEL *(1)
31 86313930 - 4 SWITCH, W/COUPLER, N.O. *(1)
BASIC (QTY 1)
DELUXE (QTY 1)
*SEE SERIAL NUMBER PAGE
**CALL MANUFACTURER FOR SERIAL NUMBER
