86269870-pg 5-2 and 5-3, Brush – Windsor Carpet Maintainer IMIE17 10066550 User Manual
Page 17
BRUSH
86269870 01/02/08
5-2
REF
PART NO.
PRV NO.
QTY
DESCRIPTION
SERIAL NO.
FROM
NOTES:
1
86217340
270130
1
COVER, BELT, RIGHT
2
86172630
57314
2
NUT, M4, LK, SST
3
86172870
70898
6
SCR, M4X14, PHMS, DIN7985 SST
4
86224670
730396
2
SPRING, BRUSH CLIP
5
86214850
12544
2
ASSY, BRUSH & HUB
6
86217330
270129
1
COVER, BELT, LEFT
7
86216070
12535
2
ASSY, BRUSH DRIVE
8
86172840
70886
6
SCR, M5X10, PHS, FHD, SST
