BRUSH LIFT
86269870 04/02/07
5-4
REF
PART NO.
PRV NO.
QTY
DESCRIPTION
SERIAL NO.
FROM
NOTES:
1 86215580 141042 2 BRACKET,
CROSSOVER
PUSH
2
86172700
67606
4
RING, E-TYPE, 5MM ID, DIN6799
3
86215750
09156
4
BRG, FLNG, 6MM IDX7MM LONG
4
86224760
73997
4
SPRING, COM, 18.28 OD X 25L
5
86215740
09155
4
BRG, FLNG, 6MM IDX24MM LONG
6 86223620 67605 2 ROD,
LIFTING
