HOPPER
86269870 04/02/07
5-18
REF
PART NO.
PRV NO.
QTY
DESCRIPTION
SERIAL NO.
FROM
NOTES:
1
86214790
41584
1
ASM, GUIDE, HOPPER
2
86173040
70919
10
SCR, M4X10, BSHCS, SST
3
86214800
41585
1
ASM, HOPPER FRAME & PLATE
4
86173080
70933
1
SCR, 4.2 X 9.5, TAP, ZN
5
86216310
140977
1
BUMPER, STOP, HOPPER
6
86172630
57314
1
NUT, M4, LK, SST
7
86217450
270709
1
COVER, FRONT, HOPPER
