86269870-pg 5-28 and 5-29, Wiring-230v – Windsor Carpet Maintainer IMIE17 10066550 User Manual
Page 43
WIRING-230V
86269870 04/14/08
5-28
REF
PART NO.
PRV NO.
QTY
DESCRIPTION
SERIAL NO.
FROM
NOTES:
1
86218880
41594
1
HARNESS, MAIN, 230VAC
2
86226220
880462
1
WIRE, 10” BLK/18 76040
3
86226260
880468
1
WIRE, 15” ORG/18 76040 X 76040
4
86226270
880469
1
WIRE, 18” ORG/18
5
86226280
880471
1
WIRE, 9” BLK/18 76040 X 76040
6
86302450
-
1
ASM, FILTER, EMI MAIN
7
86310150
-
1
ASSY, FILTER, EMI MOTOR
