Windsor Carpet Maintainer IMIE17 10066550 - Manual (Page 29)

FRAME-DELUXE
86269870 08/20/08 5-14
REF PART NO. PRV NO. QTY DESCRIPTION
SERIAL NO.
FROM
NOTES:
1 86173050 70920 3 SCR, M4 X 40 PPHMS, SS
2 86173040 70919 3 SCR, M4 X 10 SHCSB BUTHD
3 86011610 - 1 ASSY, COVER, INSULATION, DLX
4 86217930 34450 1 FRAME, 3.5, SINGLE MOTOR
5 86225340 78952 1 TRAY, IRENEW MINI
6 86012550 - 1 JET, PROMAX, 11001
7 86004570 44067 1 JET BODY, MINI PROMAX BODY
8 86012440 - 1 MANIFOLD, SPRAYER, DLX, IMX
9 86197520 40011 1 HOSEBARB, 1/8MPT X 1/4 DL
10 86233090 20016 1 CLAMP, 1/4 ID HOSE
11 86290790 - 1 SCR, M6 X 8, CP, BLK
12 86277600 70882 1 SCR, M4 X 20, PHMS, SST
13 86222360 58009 1
NUT, M4 X 0.7, U-CLAMP, 3MM
PANEL
14 86214830 05263 1 ASSY, DOME, INSULATION
