Windsor Carpet Maintainer IMIE17 10066550 - Manual (Page 35)

MOTOR
86269870 04/14/08 5-20
REF PART NO. PRV NO. QTY DESCRIPTION
SERIAL NO.
FROM
NOTES:
1 86215320 11058 1
BELT, HTD, 15MM X 300, 60
TOOTH, RH
2 86215300 11055 1
BELT, HTD, 15MM X 325, 65
TOOTH, LH
3 86215960 140979 1 BRKT, MTR MOUNT, RH
4 86173310 87499 4 WASHER, SPRING LK, 6MM, SS
5 86173060 70921 3 SCR, SHCS, M6X60, SST
6 86217890 34451 4 FLANGE, BRG, PIVOT
7 86217590 62647 2 CVR PLATE, 1.5MM THK, PLASTIC
8 86173090 70934 1 SCR, SHCS, M6X80, SST
9 86222530 66869 1 PEDAL, FOOT, HANDLE RELEASE
10 86291480 - 1 BRKT, FOOT PEDAL, SWITCH
11 86173100 70935 1 SCR, M3X6, BSHCS, SST
12 86173180 70948 1 SCR, 10M8X55, SHLD, BLK
13 86224620 730376 1 SPRING, TORSION, 19.38 OD
14 86215950 140978 1 BRKT, MTR MOUNT, LH
15A 86222200 54206 1 MOTOR, SINGLE, 3.5” DIA 120V ONLY
15B 86222210 54216 1 MOTOR, 230V, IMIE 230V ONLY
- 86216180 141057 1 BRUSH SET, 120V VAC, IM
120V & 230V,
NOT SHOWN
16 86223780 70896 2 SCR, M4X8, CP, BLK
17 86223340 64124 2 PULLEY, HTD, 5MM, 15W, 18T
18 86018550 70949 1 SCR, M6X20, CP, BLK
