Windsor Carpet Maintainer IMIE17 10066550 - Manual (Page 45)

WIRING - 120V DELUXE
86269870 01/02/08 5-30
REF PART NO. PRV NO. QTY DESCRIPTION
SERIAL NO.
FROM
NOTES:
1 86218820 41563 1 HARNESS, MAIN
2 86226220 880462 1 WIRE, 10” BLK/18 76040
3 86226260 880468 1 WIRE, 15” ORG/18 76040 X 76040
4 86226270 880469 1 WIRE, 18” ORG/18
5 86226280 880471 1 WIRE, 9” BLK/18 76040 X 76040
6 86013120 - 1 HARNESS, PUMP HOUSING, DLX
7 86013090 - 1 WIRE, 9.5” GRN/18
8 86013110 - 1 WIRE, 4 W/WIRE JOINT, BLK
9 86013950 - 1 WIRE ASSY, W/2 PIN CONN, DLX
