FRAME
86269870 04/14/08
5-12
REF
PART NO.
PRV NO.
QTY
DESCRIPTION
SERIAL NO.
FROM
NOTES:
1
86225340
78952
1
TRAY, IRENEW MINI
2
86217930
34450
1
FRAME, 3.5”, SINGLE MOTOR
3
86214820
05262
1
ASSY, COVER, INSULATION
4
86277600
70882
1
SCR, M4X20, PPHMS, SST
5 86222360 58009 1
NUT, M4X0.7, U-CLAMP, 3MM
PANEL
6
86214830
05263
1
ASSY, DOME, INSULATION
7
86173050
70920
3
SCR, M4X40, PPHMS, SST
