7–3 SCANTEAM 3400PDF User’s Guide
Wand Emulation
3400PDF/XX–X2
Conventional wand data format is provided at the modular connector in the
scanner handle.
Signal Function
Interface cables normally supplied with scanner model 3400PDF/XX-X2 are
terminated with a 10 pin modular plug(P1) and a 9 pin Type D
(Squeeze-to-release) connector (P2) that is compatible with all Welch Allyn
terminals. See chart below.
4
3
6
7
2 8
7
4
2
P2 P1
9 Pin Type D Female 10 Pin Modular Plug
Pin 1
Pin 10
6 9
1 5
Ground
Prog 1
Barcode
+5VDC
Braid
Supply Ground
Tied to 5 Volt Power
Bar Code Data Output
5 Volt Power Connection
Cord Shield
P1 P2
View A–A
P2 connects to
your terminal.
P1 connects to the
scanner handle.
