5–2 SCANTEAM 3400PDF User’s Guide
Cloning Utility
Clone Destination
Scanning the Clone Master bar code will transfer the firmware contents of the
master" unit to the destination" or installed unit. First, you must follow the
steps below to initiate the cloning procedure:
1) Connect the destination (installed) unit to one of the 8 pin modular
connectors on the cloning cable.
2) Connect the master unit (containing the new or updated software) to
the remaining 8 pin modular connector on the cloning cable.
3) Make sure that both units are powered On, and then scan the Clone
Destination bar code withthe destination unit.
5) The master unit will start transferring its firmware contents to the
installedĂ/Ădestination unit.
6) When cloning is complete, the master unit will double beep. This
process takes about 30 seconds.
Clone Master
4) Now scan the Clone Master bar code withthe master unit.
