Application 23
Manual One-Sided Griddle

One Heat Channel

Introduction to Application 23 . . . . . . . . . . . . . 31
Configuration Mode Quick Reference . . . . . . . . 33
Step 7 Design a Faceplate Overlay . . . . . . . . . . 35
Step 8 Operate the Controller . . . . . . . . . . . . . 36

Application 23 allows you to program a menu to control one temperature channel and
cooking time for a manual one-sided griddle.

Overview of Key Steps

1.

Install the M

INI

C

HEF

2000.

2. Wire the controller.

3. Configure the controller.

4. Program the menu.

5. Set the controller security.

6. Set the Real-time Clock.

For instructions on Steps 1, 2, 3, 4, 5 and 6, see the Hardware & Software Setup Guide.

7. Design, manufacture and apply faceplate overlay for end-users. (For a suggested

design to suit this application, see this section. For overlay dimensions and guide-
lines, see the Hardware & Software Setup Guide.)

8. Operate the controller. (See this application guide.)

23
