Application 21
Manual Clam Shell Griddle
Two Heat Channels
Introduction to Application 21 . . . . . . . . . . . . . 11
Configuration Mode Quick Reference . . . . . . . . 13
Step 7 Design a Faceplate Overlay . . . . . . . . . . 15
Step 8 Operate the Controller . . . . . . . . . . . . . 16
Application 21 allows you to control cooking temperatures and cooking times using a
clam shell griddle (two-sided griddle). There are two heat channels, Channel 1 (typically
bottom griddle) and Channel 2 (typically top griddle), and one cooking time.
Overview of Key Steps
1.
Install the M
INI
C
HEF
2000.
2. Wire the controller.
3. Configure the controller.
4. Program the menu.
5. Set the controller security.
6. Set the Real-time Clock.
For instructions on Steps 1, 2, 3, 4, 5 and 6, see the Hardware & Software Setup Guide.
7. Design, manufacture and apply faceplate overlay for end-users. (For a suggested
design to suit this application, see this section. For overlay dimensions and guide-
lines, see the Hardware & Software Setup Guide.)
8. Operate the controller. (See this application guide.)
