Package contents
(1) TORSION TUBE
NoTe: DEPENDING ON ThE DOOR MODEL, SOME PARTS
LISTED WILL NOT BE SUPPLIED IF NOT NECESSARY. REAR
SUPPORTS MAY OR MAY NOT BE INCLUDED WITh YOUR DOOR.
DOOR SECTIONS
(AS REqUIRED)
WEAThER SEAL &
NAILS (IF INCLUDED)
(2) FULLY ADjUSTABLE
Rh/Lh FLAGANGLE
ROLLERS
(AS REqUIRED)
TOP BRACKET
ASSEMBLY
(AS REqUIRED)
#1, #2, #3, #4 hINGES
& #1 hALF hINGES
(AS REqUIRED)
RIGhT AND LEFT
BOTTOM BRACKETS
(AS REqUIRED)
#6 SCREW EYE AND
PULL ROPE
(AS REqUIRED)
LIFT hANDLES
(AS REqUIRED)
jAMB BRACKETS
(AS REqUIRED)
MANUAL
8800 & 8850 Aluminum Full View
IMPORTANT NOTICE! Read these instructions carefully before
attempting installation. If in question about
any of the procedures, do not perform the
work. Instead, have a qualifi ed door agency
do the installation or repairs.
© Copyright 2008 Wayne-Dalton Corp. Part No. xxxxxx NEW 3/17/2008
Torsion Spring Installation Instructions and Owner’s Manual
Portland Source Plant
Wayne-Dalton Corp. P.O. Box 67 Mt. Hope, OH 44660 www.wayne-dalton.com
COUNTERBALANCE CABLES
(2) hORIzONTAL TRACK WITh ATTAChED hORIzONTAL ANGLE Rh/Lh
(2) VERTICAL
Rh/Lh TRACK
(1) CENTER BRACKET
BUShING
Rh/Lh TORSION
SPRINGS (AS REqUIRED)
RIGhT & LEFT DRUMS (1) CENTER BRACKET
RIGhT & LEFT
END BEARING BRACKETS
(2) WALL
ANGLES
