24 ViewSonic PJ751
Picture 1 Menu
Using the PICTURE 1 menu, the five items shown in the Table below
can be performed.
Perform each operation according to the instructions in the Table.
Picture 2 Menu
Using the PICTURE 2 menu, the five items shown in the Table below
can be performed.
Perform each operation according to the instructions in the Table.
Item Description
COLOR BAL R
Adjust Red Color Balance: Dark Light
COLOR BAL B
Adjust Blue Color Balance: Dark Light
SHARPNESS
Adjust Sharpness (for VIDEO/S-VIDEO): Clear Soft
COLOR Adjust COLOR (for VIDEO/S-VIDEO/COMPONENT VIDEO):
Dark Light
TINT
Adjust Tint (for VIDEO/S-VIDEO): Green Red
Item Description
V POSITION
Adjust Vertical Position (for RGB): Up Down
H POSITION
Adjust Horizontal Position (for RGB): Left Right
H PHASE Adjust Horizontal Phase (for RGB/COMPONENT VIDEO):
Right Left
Adjust to eliminate flicker.
H SIZE
Adjust Horizontal Size (for RGB): Large Small
If the horizontal size adjustment is excessive, the image may not be displayed
correctly. In such a case, initialize H SIZE with the RESET button.
OVER SCAN Select Over-scan Ratio (for VIDEO/S-VIDEO/COMPONENT VIDEO):
LARGE MIDDLE SMALL
It is recommended to select SMALL to avoid flicker at the lower part of the
picture.
Example: PICTURE1 Menu
(COLOR BAL R)
Example: PICTURE2 Menu
(V POSITION)
