ViewSonic PJ1065 23
SPECIFICATIONS
Table 12: Specifications
NOTE: • These specifications are subject to change without notice.
Item Specification
Liquid crystal
projector
Panel size 3.3 cm (1.3 type)
Drive system TFT active matrix, 1024 × 768 native
Pixels 786,432 pixels (1024 horizontal × 768 vertical)
Lens Zoom lens F = 1.7 – 2.3; f = 49.0 – 64.0 mm
Lamp 275 W UHB
Speaker 1.2 W + 1.2 W (stereo)
Power supply AC 100 – 120 V, 4.7 A / AC 220 – 240 V, 2.0 A
Power consumption 440 W
Temperature range 0 – 35°C (operating)
Size 289 (W) × 139 (H) × 345 (D) mm
Weight (mass) 6.5 kg
RGB signal
input
RGB IN
1 Video: Analog 0.7 Vp-p, 75 Ω terminator (positive)
H/V. sync.: TTL level (positive/negative)
Composite sync.: TTL level
D-sub 15-pin shrink jack
2
DVI
TMDS, DC: 150-1200 mV / AC: 1.56 Vp-p
TTL Level (Positive/Negative)
AUDIO IN
RGB1
200m Vrms, 50 k Ω (max. 3.0Vp-p)
Stereo mini jack
DVI
RGB2
Video signal
input
VIDEO
1.0Vp-p, 75 Ω terminator
RCA jack
S-VIDEO
Brightness signal: 1.0 Vp-p, 75 Ω terminator
Color signal: 0.286Vp-p (burst signal), 75 Ω terminator
Mini DIN 4-pin jack
COMPONENT
VIDEO
Y 1.0 Vp-p, 75 Ω Terminator (positive)
C
B
/P
B
0.7 Vp-p, 75 Ω Terminator (positive)
C
R
/P
R
0.7 Vp-p, 75 Ω Terminator (positive)
AUDIO
L/MONO 200m Vrms, 50 k Ω (max. 3.0 Vp-p)
RCA jack R
Signal output
RGB OUT
Video: Analog 0.7 Vp-p, 75 Ω output impedance (positive)
H/V. sync.: TTL level (positive/negative)
Composite sync.: TTL level
D-sub 15-pin shrink jack
AUDIO OUT
200m Vrms, output impedance 1 k Ω (max. 3.0Vp-p)
Stereo mini jack
Control
functions
CONTROL D-sub 15-pin shrink plug
USB USB jack (B type)
Optional parts Lamp: PRJ-RLC--002
