Setting Up and Adjusting Your Phone

SELECTING THE LOCATION

Select a location for the ANA9620 to avoid excessive heat or

humidity. The base of your ANA9620 can be placed on a

desk or tabletop near a standard 120V AC outlet and

telephone line jack. The base can also be mounted on a

standard AT&T or GTE wall plate using the included wall

mount adapter. Keep the base and handset away from

sources of electrical noise (motors, fluorescent lighting,

computers).

CONNECTING THE TELEPHONE LINE

There are three types of phone outlets:

▼

1) Modular Jack

Plug the telephone line cord from the base into a standard

modular telephone jack(s). (Note: If you do not have a

modular jack, contact your local telephone company for

information on the installation of these jacks.)

▼

2) 4-Prong Jack

An adapter (not included) is required. The adapter plugs into

the 4-prong jack and the telephone line cord plugs into the

adapter.

▼

3) Hard-wired Jack

A modular jack converter (not included) is required. You

may need to rewire when connecting the converter (making

color-coded connections).

Your Uniden telephone dealer or a telephone supply

store can advise you on the proper adapter or converter.

ADJ

USTI

TTIN

SETTI

G
U

TIP

Before choosing a location
for your phone, read the
Installation
Considerations included in
the Precautions and
Important Safety
Instructions brochure.
