XL-12000S
MANAGED, HIGH-SPEED NETWORK MODEM USER GUIDE
48 TUT SYSTEMS 9.0 MODEM STATISTICS
9.0 Modem Statistics
The XL-12000S provides modem status and statistics.
Note: Accessing these screens may effect modem performance during
heavy use.
To return to the main menu, press .
9.1 Modem Status
This screen displays the expanded status detail for the selected
modem. The DSL line state, Master/Slave selection, and modem
name are on the top and modem network statistics appear on
the bottom.
Statistics are presented as “rolling totals.” Powering down or reboot-
ing the modem will clear these registers.
Figure 9.1 Modem Status Screen
From the Main Menu, select “S” for status.
