Page 46
XL-12000S
MANAGED, HIGH-SPEED NETWORK MODEM USER GUIDE
38
TUT SYSTEMS
7.0 CONFIGURE THE MODEM
FIELD
DESCRIPTION
Subnet Mask:
A mask selected by the Network Administrator to provide
(LAN and DSL)
a specific subset of address numbers. A valid subnet
mask is required for routing options 2 or 3. Enter 0.0.0.0
for default subnet mask setting. This address is used for a
remote management session to the modem.
DSL IP Address:
A unique address number supplied by the Network
(Right side of screen)
Administrator for the DSL side of the modem. A valid DSL
IP Address is required for routing options 2 or 3. This
address can also be used for remote management when
opening a Telnet session to the modem.
Static Routing Table:
Destination:
IP address of the destination (host or network).
A destination address of 0.0.0.0 designates the default
gateway entry.
Mask:
Subnet mask address. A mask selected by the Network
Administrator to provide a specific subset of address
numbers.
Gateway:
IP Address of the next router, which may be an external
router or the other modem across the DSL link.
Hops:
Number of routers between this network and the
external gateway router.
Note: Unused routing table entries are deleted by
entering a zero (or blank) hop count. Only entries with
a non-zero hop count are used. Static routing entries
do not affect bridging. Entering a zero and pressing
