Example 4 Unsecured Mode, vertical spacing with various enlargement factors
Legend
A – a single line Feed (1/6")
B – Factor 6 character; heigth
C – Factor 7 character; height additional space is added to gain a full Line Feed
D – Factor 4 character; height
E – Factor 5 character; height additional space is added to gain a full Line Feed
▲ – start, actual print (cursor)-position
● – end, actual print-position
Description The room will be occupied to fit the highest character in one line. Characters which will
not meet the 1/6" grid *) are adding additional space to fill the room to the next possible
line.
*) this value may change due to actual line density setting.
A
B
D
E
C
6 3 LF 1
12
1
6
Ч Ч ь
7 1
12
Ч
4 2 LF 1
12
1
6
Ч Ч ь
5 1
12
Ч
48 Various Examples
