Barcode Width By specifying an ASCII value from 0 to 3, the barcode width can be defined. This allows
ideal adaption to the scanner specifications, particularly for long-range scanners.
Table 1
Header
Para-
meter
Normal Compressed
1
)
older printer
types
(e.g.MT230)
older printer
types
(e.g.MT230)
Width of
the
narrow bar
x = 0
x = 1
x = 2
x = 3 0.53 mm
0.74 mm
1.16 mm
1.38 mm 0.54 mm
0.67 mm
1.09 mm
1.30 mm 0.48 mm
0.69 mm
1.16 mm
1.33 mm 0.32 mm
0.53 mm
0.74 mm
0.95 mm 0.33 mm
0.43 mm
0.65 mm
0.88 mm 0.27 mm 3)
0.37 mm 3)
0.59 mm 3)
0.90 mm 3)
Width of
the
narrow
space
y = 0
y = 1
y = 2
y = 3 0.53 mm
0.74 mm
1.16 mm
1.38 mm 0.54 mm
0.67 mm
1.09 mm
1.30 mm 0.48 mm
0.69 mm
1.16 mm
1.33 mm 0.32 mm
0.53 mm
0.74 mm
0.95 mm 0.33 mm
0.43 mm
0.65 mm
0.88 mm 0.27 mm 3)
0.37 mm 3)
0.59 mm 3)
0.90 mm 3)
Enlarge-
ment
factor
z = 0
z = 1
z = 2
z = 3 2.0 : 1
2.5 : 1
3.0 : 1
3.5 : 1 2.0 : 1 2 )
2.5 : 1 2 )
3.0 : 1 2 )
3.5 : 1 2 )
EAN/UPC Barcode
(X, Y = unregarded):
Table 2 Header Parameter Normal Compressed 1 )
Enlargement
factor
z = 0
z = 1 1.95 : 1
1.60 : 1 1.30 : 1
0.95 : 1
1) These values are true, if "Compressed Print" is selected in the menu (see print feature [F]).
2)
Note: It is recommended to set the bar width equal to the space width (x=y).
3) Printer-dependent reference value.
