Page 32
32
PKGP-PRC001-EN
Electrical
Data
*
Indicates both downflow and horizontal units.
Table ED-5 — Electrical Characteristics — Compressor Motor And Condenser Motor — 60 Cycle
Unit
Tons
Model No.
No.
Volts
Phase
HP
2
RPM
RLA
LRA
No. Phase
HP
FLA
LRA
WC
*
150B3
2
208-230
3
6.00
3450
21.7
156
2
1
.50
3.2
8.8
12½
WC
*
150B4
2
460
3
6.00
3450
10.0
75
2
1
.50
1.6
4.0
WC
*
150BW
2
575
3
6.00
3450
8.2
54
2
1
.50
1.3
3.2
WC
*
180B3
2
208-230
3
5.70/9.00
3450/3500
30.1/20.4
225/156
2
1
.50
3.2
8.8
15
WC
*
180B4
2
460
3
5.70/9.00
3450/3500
15.6/10.8
114/75
2
1
.50
1.6
4.0
WC
*
180BW
2
575
3
5.70/9.00
3450/3500
12.1/8.5
80/54
2
1
.50
1.3
3.2
WC
*
240B3
2
208-230
3
9.00
3500
30.1
225
2
1
1.00
5.5
18.3
20
WC
*
240B4
2
460
3
9.00
3500
15.8
114
2
1
1.00
2.9
9.3
WC
*
240BW
2
575
3
9.00
3500
12.2
80
2
1
1.00
2.0
5.7
Notes:
1
Amp draw for each motor; multiply value by numbers of motors to determine total amps.
2. HP for each compressor.
Amps
1
Amps
1
Condenser Fan Motors
Compressor Motors
