Performance
Data
(20 Ton)
Table PD-4 — Gross Cooling Capacities (MBh) 20 Ton Downflow Three Phase WCD240B
Ambient Temperature (F)
85 95 105 115
Enter.
CFM Dry Entering Wet Bulb (F)
Bulb 61 67 73 61 67 73 61 67 73 61 67 73
Airflow (F) MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC
75 212.0 177.0 233.0 137.0 243.0 89.7 198.0 173.0 228.0 133.0 244.0 87.3 179.0 164.0 211.0 130.0 239.0 83.1 160.0 154.0 189.0 115.0 225.0 76.8
80 219.0 218.0 234.0 165.0 246.0 122.0 204.0 204.0 229.0 168.0 247.0 123.0 188.0 188.0 212.0 160.0 240.0 118.0 172.0 172.0 190.0 150.0 225.0 112.0
7200 85 229.0 229.0 236.0 197.0 249.0 148.0 220.0 220.0 231.0 202.0 249.0 153.0 205.0 205.0 215.0 196.0 242.0 153.0 189.0 189.0 194.0 186.0 226.0 146.0
90 238.0 238.0 238.0 227.0 252.0 174.0 234.0 234.0 233.0 233.0 252.0 183.0 222.0 222.0 222.0 222.0 242.0 186.0 206.0 206.0 206.0 206.0 227.0 181.0
75 218.0 193.0 237.0 144.0 244.0 91.2 204.0 185.0 232.0 139.0 246.0 89.1 184.0 175.0 216.0 131.0 242.0 85.0 162.0 162.0 193.0 128.0 229.0 78.8
80 224.0 224.0 239.0 173.0 247.0 123.0 213.0 213.0 233.0 176.0 249.0 126.0 196.0 196.0 217.0 170.0 243.0 124.0 180.0 180.0 195.0 160.0 230.0 117.0
8000 85 234.0 234.0 241.0 207.0 250.0 150.0 228.0 228.0 235.0 213.0 252.0 158.0 215.0 215.0 221.0 210.0 244.0 159.0 197.0 197.0 197.0 197.0 230.0 155.0
90 242.0 242.0 245.0 238.0 253.0 178.0 240.0 240.0 240.0 240.0 254.0 190.0 231.0 231.0 231.0 231.0 246.0 195.0 216.0 216.0 216.0 216.0 232.0 193.0
75 223.0 201.0 238.0 148.0 245.0 93.4 209.0 196.0 235.0 145.0 248.0 90.6 189.0 186.0 220.0 138.0 244.0 86.8 168.0 168.0 196.0 136.0 232.0 80.6
80 229.0 229.0 241.0 177.0 248.0 139.0 220.0 220.0 236.0 184.0 250.0 128.0 204.0 204.0 221.0 180.0 246.0 129.0 186.0 186.0 199.0 170.0 233.0 122.0
8800 85 238.0 238.0 244.0 212.0 252.0 152.0 234.0 234.0 239.0 223.0 253.0 161.0 222.0 222.0 226.0 223.0 247.0 165.0 205.0 205.0 205.0 205.0 233.0 164.0
90 245.0 245.0 247.0 245.0 255.0 181.0 245.0 245.0 245.0 245.0 256.0 195.0 238.0 238.0 238.0 238.0 249.0 203.0 224.0 224.0 224.0 224.0 236.0 205.0
75 226.0 208.0 241.0 151.0 246.0 94.2 214.0 206.0 236.0 148.0 249.0 91.4 191.0 191.0 223.0 144.0 245.0 88.6 174.0 174.0 199.0 143.0 235.0 82.4
80 232.0 232.0 243.0 185.0 250.0 126.0 226.0 226.0 238.0 190.0 251.0 115.0 211.0 211.0 225.0 189.0 247.0 123.0 193.0 193.0 203.0 179.0 235.0 127.0
9600 85 241.0 241.0 245.0 222.0 253.0 155.0 239.0 239.0 242.0 231.0 255.0 165.0 229.0 229.0 229.0 229.0 249.0 170.0 212.0 212.0 212.0 212.0 236.0 171.0
90 248.0 248.0 247.0 247.0 256.0 184.0 248.0 248.0 248.0 248.0 258.0 200.0 243.0 243.0 243.0 243.0 252.0 210.0 231.0 231.0 231.0 231.0 239.0 215.0
Notes:
1. Dry Coil Condition. Total Gross Cooling Capacity (MBh) shown to the left is not applicable. In this case the Sensible Heat Capacity (SHC) is the total capacity.
2. All capacities shown are gross and have not considered indoor fan heat. To obtain net cooling subtract indoor fan heat.
3. MBH = Total Gross Capacity
4. SHC = Sensible Heat Capacity
Table PD-5 — Gross Cooling Capacities (MBh) 20 Ton Horizontal Three Phase WCD240B
Ambient Temperature (F)
85 95 105 115
Enter.
CFM Dry Entering Wet Bulb (F)
Bulb 61 67 73 61 67 73 61 67 73 61 67 73
Airflow (F) MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC
75 217.0 181.0 238.0 140.0 248.0 91.4 202.0 177.0 233.0 136.0 249.0 88.9 183.0 167.0 215.0 132.0 244.0 84.7 163.0 157.0 192.0 117.0 229.0 78.3
80 224.0 223.0 239.0 168.0 250.0 124.0 208.0 208.0 233.0 171.0 251.0 126.0 192.0 192.0 216.0 163.0 245.0 121.0 175.0 175.0 194.0 153.0 229.0 114.0
7200
85 233.0 233.0 241.0 201.0 253.0 151.0 224.0 224.0 235.0 206.0 254.0 156.0 209.0 209.0 219.0 200.0 246.0 156.0 192.0 192.0 198.0 190.0 230.0 149.0
90 242.0 242.0 242.0 230.0 256.0 177.0 238.0 238.0 238.0 238.0 257.0 186.0 226.0 226.0 226.0 226.0 247.0 189.0 210.0 210.0 210.0 210.0 231.0 185.0
75 223.0 197.0 241.0 147.0 249.0 93.5 208.0 188.0 236.0 142.0 251.0 90.8 188.0 178.0 220.0 134.0 247.0 86.6 165.0 165.0 196.0 130.0 233.0 80.3
80 228.0 228.0 244.0 176.0 252.0 126.0 217.0 217.0 237.0 180.0 254.0 128.0 200.0 200.0 221.0 174.0 248.0 126.0 183.0 183.0 199.0 163.0 234.0 119.0
8000
85 238.0 238.0 246.0 211.0 255.0 153.0 233.0 233.0 240.0 217.0 256.0 161.0 219.0 219.0 225.0 214.0 249.0 163.0 201.0 201.0 201.0 201.0 234.0 158.0
90 246.0 246.0 250.0 243.0 258.0 181.0 245.0 245.0 245.0 245.0 259.0 194.0 235.0 235.0 235.0 235.0 251.0 199.0 220.0 220.0 220.0 220.0 236.0 197.0
75 228.0 205.0 243.0 151.0 250.0 95.2 213.0 200.0 239.0 147.0 252.0 92.3 193.0 189.0 224.0 140.0 249.0 88.5 172.0 172.0 200.0 138.0 237.0 82.1
80 233.0 233.0 245.0 181.0 253.0 142.0 224.0 224.0 240.0 187.0 255.0 131.0 208.0 208.0 225.0 183.0 250.0 131.0 190.0 190.0 203.0 173.0 237.0 124.0
8800
85 242.0 242.0 248.0 216.0 256.0 155.0 239.0 239.0 243.0 227.0 258.0 165.0 227.0 227.0 230.0 227.0 252.0 169.0 209.0 209.0 209.0 209.0 238.0 167.0
90 249.0 249.0 252.0 250.0 260.0 184.0 249.0 249.0 249.0 249.0 261.0 199.0 242.0 242.0 242.0 242.0 254.0 207.0 228.0 228.0 228.0 228.0 240.0 208.0
75 231.0 212.0 245.0 153.0 251.0 96.0 218.0 210.0 241.0 151.0 253.0 93.1 195.0 195.0 227.0 146.0 250.0 90.3 177.0 177.0 203.0 146.0 239.0 84.0
80 237.0 237.0 247.0 188.0 254.0 128.0 230.0 230.0 243.0 194.0 256.0 117.0 215.0 215.0 229.0 193.0 251.0 125.0 196.0 196.0 207.0 183.0 240.0 130.0
9600
85 245.0 245.0 249.0 226.0 258.0 158.0 243.0 243.0 246.0 236.0 260.0 168.0 233.0 233.0 233.0 233.0 253.0 173.0 216.0 216.0 216.0 216.0 241.0 175.0
90 253.0 253.0 252.0 252.0 261.0 187.0 253.0 253.0 253.0 253.0 263.0 204.0 247.0 247.0 247.0 247.0 256.0 214.0 235.0 235.0 235.0 235.0 244.0 219.0
Notes:
1. Dry Coil Condition. Total Gross Cooling Capacity (MBh) shown to the left is not applicable. In this case the Sensible Heat Capacity (SHC) is the total capacity.
2. All capacities shown are gross and have not considered indoor fan heat. To obtain net cooling subtract indoor fan heat.
3. MBH = Total Gross Capacity
4. SHC = Sensible Heat Capacity
