Performance
Data
(12½ Ton)
Table PD-2 — Gross Cooling Capacities (MBh)
12½ Ton Horizontal Three Phase
WCH150B
Ambient Temperature (F)
85
95
105
115
Enter.
Dry
Entering Wet Bulb (F)
CFM
Bulb
61
67
73
61
67
73
61
67
73
61
67
73
Airflow
(F)
MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC
75
140.0 113.0 153.0 91.1 159.0 58.0 128.0 106.0 149.0 83.3 160.0 56.2 116.0 100.0 137.0 82.9 157.0 53.5 104.0 93.5 124.0 76.7 147.0 48.9
4500
80
141.0 134.0 154.0 105.0 160.0 78.3 130.0 128.0 149.0 104.0 161.0 77.5 119.0 119.0 138.0 98.4 157.0 74.3 109.0 109.0 124.0 91.9 148.0 69.6
85
146.0 146.0 155.0 124.0 161.0 94.3 139.0 139.0 149.0 125.0 162.0 96.0 129.0 129.0 138.0 119.0 158.0 95.0 119.0 119.0 125.0 113.0 148.0 90.2
90
153.0 153.0 156.0 143.0 163.0 110.0 148.0 148.0 151.0 145.0 163.0 114.0 140.0 140.0 139.0 139.0 158.0 115.0 130.0 130.0 129.0 129.0 148.0 111.0
75
143.0 119.0 154.0 93.3 160.0 59.0 132.0 113.0 151.0 86.8 161.0 57.4 119.0 106.0 141.0 88.2 159.0 54.7 107.0 99.8 127.0 81.8 151.0 50.8
5000
80
145.0 142.0 156.0 109.0 162.0 79.9 134.0 134.0 152.0 109.0 162.0 79.6 124.0 124.0 141.0 104.0 159.0 77.3 114.0 114.0 128.0 97.7 151.0 72.9
85
150.0 150.0 157.0 129.0 164.0 96.6 145.0 145.0 152.0 131.0 164.0 98.7 135.0 135.0 142.0 127.0 160.0 99.1 125.0 125.0 129.0 121.0 151.0 95.5
90
156.0 156.0 158.0 149.0 164.0 112.0 153.0 153.0 153.0 153.0 165.0 118.0 146.0 146.0 146.0 146.0 161.0 120.0 136.0 136.0 136.0 136.0 151.0 118.0
75
145.0 124.0 156.0 95.9 160.0 60.1 135.0 119.0 153.0 90.8 162.0 58.5 122.0 112.0 144.0 93.2 160.0 55.8 110.0 106.0 130.0 86.9 153.0 52.3
5500
80
147.0 147.0 157.0 111.0 162.0 80.8 139.0 139.0 154.0 114.0 163.0 81.0 129.0 129.0 144.0 110.0 161.0 80.1 118.0 118.0 130.0 103.0 154.0 76.0
85
154.0 154.0 158.0 133.0 164.0 97.9 149.0 149.0 155.0 137.0 165.0 101.0 140.0 140.0 145.0 135.0 162.0 103.0 130.0 130.0 132.0 128.0 154.0 100.0
90
159.0 159.0 160.0 153.0 166.0 115.0 157.0 157.0 157.0 157.0 167.0 121.0 151.0 151.0 151.0 151.0 163.0 125.0 141.0 141.0 141.0 141.0 154.0 124.0
75
147.0 129.0 157.0 98.2 161.0 60.6 138.0 125.0 155.0 92.9 163.0 59.5 125.0 118.0 146.0 88.7 161.0 57.1 111.0 111.0 132.0 91.8 155.0 52.5
6000
80
150.0 150.0 158.0 114.0 163.0 81.5 144.0 144.0 156.0 118.0 164.0 82.1 133.0 133.0 147.0 115.0 162.0 82.3 122.0 122.0 133.0 109.0 155.0 78.8
85
156.0 156.0 160.0 136.0 165.0 99.1 153.0 153.0 157.0 143.0 166.0 103.0 145.0 145.0 148.0 142.0 163.0 106.0 134.0 134.0 134.0 134.0 156.0 105.0
90
161.0 161.0 162.0 157.0 167.0 117.0 160.0 160.0 160.0 160.0 168.0 124.0 155.0 155.0 155.0 155.0 164.0 130.0 146.0 146.0 146.0 146.0 156.0 130.0
Notes:
1. Dry Coil Condition. Total Gross Cooling Capacity (MBh) shown to the left is not applicable. In this case the Sensible Heat Capacity (SHC) is the total capacity.
2. All capacities shown are gross and have not considered indoor fan heat. To obtain net cooling subtract indoor fan heat.
3. MBH = Total Gross Capacity
4. SHC = Sensible Heat Capacity
Table PD-1 — Gross Cooling Capacities (MBh)
12½ Ton Downflow Three Phase
WCD150B
Ambient Temperature (F)
85
95
105
115
Enter.
Dry
Entering Wet Bulb (F)
CFM
Bulb
61
67
73
61
67
73
61
67
73
61
67
73
Airflow
(F)
MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC
75
140.0 113.0 153.0 90.8 158.0 57.9 128.0 106.0 149.0 83.3 160.0 56.3 116.0 99.8 137.0 83.3 157.0 53.5 104.0 93.3 124.0 77.1 148.0 48.9
4500
80
141.0 134.0 154.0 105.0 159.0 78.3 130.0 128.0 149.0 104.0 161.0 77.4 119.0 119.0 138.0 98.3 157.0 74.3 109.0 109.0 125.0 91.8 148.0 69.6
85
146.0 146.0 155.0 124.0 160.0 94.3 139.0 139.0 150.0 125.0 162.0 95.8 129.0 129.0 138.0 119.0 158.0 94.9 119.0 119.0 125.0 113.0 148.0 90.2
90
153.0 153.0 156.0 143.0 162.0 111.0 148.0 148.0 151.0 145.0 163.0 114.0 140.0 140.0 139.0 139.0 158.0 114.0 130.0 130.0 129.0 129.0 148.0 111.0
75
143.0 119.0 154.0 93.5 159.0 59.0 132.0 113.0 152.0 87.2 161.0 57.4 119.0 106.0 141.0 88.6 159.0 54.8 107.0 99.5 127.0 82.3 151.0 50.9
5000
80
145.0 141.0 156.0 108.0 160.0 79.2 134.0 134.0 152.0 109.0 162.0 79.5 124.0 124.0 141.0 104.0 160.0 77.2 114.0 114.0 128.0 97.5 151.0 72.9
85
150.0 150.0 157.0 128.0 162.0 97.0 145.0 145.0 153.0 131.0 164.0 98.4 135.0 135.0 142.0 127.0 160.0 98.9 125.0 125.0 129.0 120.0 152.0 95.3
90
156.0 156.0 158.0 148.0 164.0 112.0 153.0 153.0 155.0 153.0 165.0 118.0 146.0 146.0 146.0 146.0 161.0 120.0 136.0 136.0 136.0 136.0 152.0 118.0
75
145.0 124.0 155.0 96.1 160.0 60.0 135.0 119.0 153.0 90.7 162.0 58.5 122.0 112.0 144.0 93.8 160.0 55.7 110.0 105.0 130.0 87.4 154.0 52.4
5500
80
147.0 147.0 157.0 111.0 162.0 80.5 139.0 139.0 154.0 113.0 163.0 80.9 129.0 129.0 144.0 110.0 161.0 79.9 118.0 118.0 131.0 103.0 154.0 75.9
85
153.0 153.0 158.0 132.0 164.0 97.4 149.0 149.0 155.0 137.0 165.0 101.0 140.0 140.0 145.0 134.0 162.0 102.0 130.0 130.0 132.0 128.0 154.0 100.0
90
159.0 159.0 160.0 152.0 166.0 115.0 157.0 157.0 157.0 157.0 166.0 121.0 151.0 151.0 151.0 151.0 163.0 125.0 141.0 141.0 141.0 141.0 154.0 124.0
75
147.0 128.0 156.0 98.4 160.0 60.0 138.0 125.0 155.0 92.7 163.0 59.5 125.0 118.0 147.0 88.6 161.0 57.2 112.0 111.0 132.0 92.4 155.0 52.5
6000
80
150.0 150.0 158.0 113.0 162.0 81.2 144.0 144.0 156.0 117.0 164.0 82.1 133.0 133.0 147.0 115.0 162.0 82.1 122.0 122.0 133.0 108.0 156.0 78.7
85
156.0 156.0 159.0 135.0 164.0 98.4 153.0 153.0 157.0 142.0 166.0 103.0 145.0 145.0 148.0 141.0 163.0 106.0 134.0 134.0 134.0 134.0 156.0 104.0
90
160.0 160.0 161.0 156.0 166.0 116.0 160.0 160.0 160.0 160.0 167.0 123.0 155.0 155.0 155.0 155.0 165.0 129.0 146.0 146.0 146.0 146.0 157.0 130.0
Notes:
1. Dry Coil Condition. Total Gross Cooling Capacity (MBh) shown to the left is not applicable. In this case the Sensible Heat Capacity (SHC) is the total capacity.
2. All capacities shown are gross and have not considered indoor fan heat. To obtain net cooling subtract indoor fan heat.
3. MBH = Total Gross Capacity
4. SHC = Sensible Heat Capacity
