Electrical data, 575 volts three phase – Trane PKGP-PRC001-EN User Manual
Page 30
30
PKGP-PRC001-EN
Electrical
Data
Table ED-3 — Unit Wiring With Electric Heat (Single Point Connection, Continued)
Standard Indoor Motor
Oversize Indoor Motor
To Use
Heater
Heater
Control
Max Fuse Size or
Max Fuse Size or
Tons
With
Model No.
KW Rating
1
Stages
MCA
Max Circuit Breaker
2
MCA
Max Circuit Breaker
2
575 Volts Three Phase
AYDHTRKW18A
18.0
1
47
50
49
50
WCD150BW
AYDHTRKW36A
36.0
2
69
70
71
80
AYDHTRKW54A
54.0
2
90
90
93
100
12½
AYHHTRNW18A
18.0
1
47
50
49
50
WCH150BW
AYHHTRQW36A
36.0
2
69
70
71
80
AYHHTRPW54A
54.0
2
90
90
93
100
AYDHTRKW18A
18.0
1
52
60
54
60
WCD180BW
AYDHTRKW36A
36.0
2
74
80
76
80
AYDHTRKW54A
54.0
2
96
100
98
100
15
AYHHTRNW18A
18.0
1
52
60
54
60
WCH180BW
AYHHTRQW36A
36.0
2
74
80
76
80
AYHHTRPW54A
54.0
2
96
100
98
100
AYDHTRLW36A
36.0
2
81
90
84
90
WCD240BW
AYDHTRLW54A
54.0
2
103
110
106
110
AYDHTRKW72A
72.0
2
125
125
128
150
20
AYHHTRNW36A
36.0
2
81
90
84
90
WCH240BW
AYHHTRNW54A
54.0
2
103
110
106
110
AYHHTRNW72A
72.0
2
125
125
128
150
Notes:
1. Heater kw ratings are at 600V for 575V unit
2. HACR type circuit breaker per NEC.
