Electrical
Data
Table ED-3 — Unit Wiring With Electric Heat (Single Point Connection, Continued)
Standard Indoor Motor
Oversize Indoor Motor
To Use
Heater
Heater
Control
Max Fuse Size or
Max Fuse Size or
Tons
With
Model No.
KW Rating
1
Stages
MCA
Max Circuit Breaker
2
MCA
Max Circuit Breaker
2
460 Volts Three Phase
AYDHTRK418A
18.0
1
58
60
61
70
WCD150B4
AYDHTRK436A
36.0
2
85
90
88
90
AYDHTRK454A
54.0
2
112
125
115
125
12½
AYHHTRP418A
18.0
1
58
60
61
70
WCH150B4
AYHHTRP436A
36.0
2
85
90
88
90
AYHHTRP454A
54.0
2
112
125
115
125
AYDHTRK418A
18.0
1
66
70
69
70
WCD180B4
AYDHTRK436A
36.0
2
93
100
96
100
AYDHTRK454A
54.0
2
120
125
123
125
15
AYHHTRP418A
18.0
1
66
70
69
70
WCH180B4
AYHHTRP436A
36.0
2
93
100
96
100
AYHHTRP454A
54.0
2
120
125
123
125
AYDHTRL436A
36.0
2
104
110
107
110
WCD240B4
AYDHTRL454A
54.0
2
131
150
134
150
AYDHTRK472A
72.0
2
158
175
161
175
20
AYHHTRN436A
36.0
2
104
110
107
110
WCH240B4
AYHHTRN454A
54.0
2
131
150
134
150
AYHHTRN472A
72.0
2
158
175
161
175
Notes:
1. Heater kw ratings are at 480V for 460V unit
2. HACR type circuit breaker per NEC.
