18 PKGP-PRC001-EN
Performance
Data
(15 Ton)
3 HP Standard Motor & Field
Supplied High Static Drive (2)
Table PD-8 — Evaporator Fan Performance — 15 Ton — WCH180B — Continued
External Static Pressure (Inches of Water)
1.10 1.20 1.30 1.40 1.50 1.60 1.70 1.80 1.90 2.00
CFM RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP
5 HP Oversized Motor & Drive 5 HP Standard Motor & Field Supplied High Static Drive Accessory (3)
4800 975 3.62 997 3.79 1018 3.95 1040 4.12 1061 4.29 1078 4.39 1082 4.25 1086 4.10 1094 4.04 1116 4.21
5400 1040 4.66 1060 4.83 1079 5.00 1098 5.18 1118 5.36 1137 5.54 1156 5.73 1174 5.91 1194 6.11 1212 6.28
6000 1107 5.89 1126 6.08 1144 6.28 1162 6.47 1180 6.66 1197 6.85 1214 7.04 1232 7.24 1250 7.44 1267 7.65
6600 1157 6.90 1186 7.36 1212 7.75 1230 7.99 1246 8.20 1263 8.42 1279 8.62 — — — — — —
7200 1191 7.62 1227 8.30 — — — — — — — — — — — — — — — —
7.5 HP Oversized Motor & Drive 7.5 HP Oversized Motor with
Field Supplied High Static Drive (4) (5)
Table PD-8 — Evaporator Fan Performance — 15 Ton — WCH180B
External Static Pressure (Inches of Water)
.10 .20 .30 .40 .50 .60 .70 .80 .90 1.00
CFM RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP
3 HP Standard Motor & Drive
4800 637 1.36 670 1.50 700 1.63 743 1.88 801 2.32 850 2.72 884 3.01 908 3.17 931 3.32 953 3.47
5400 709 1.90 738 2.06 766 2.20 793 2.34 833 2.65 884 3.12 931 3.62 969 4.02 998 4.31 1019 4.49
6000 781 2.56 808 2.74 834 2.91 858 3.06 882 3.22 918 3.55 962 4.05 1009 4.63 1049 5.15 1081 5.57
6600 854 3.37 879 3.56 903 3.75 925 3.93 947 4.10 970 4.28 1001 4.62 1039 5.11 1082 5.72 1122 6.34
7200 927 4.33 951 4.55 973 4.76 994 4.96 1014 5.15 1035 5.34 1055 5.54 1081 5.85 1115 6.33 1152 6.94
5 HP Oversized Motor & Drive
Table PD-7 — Evaporator Fan Performance — 15 Ton — WCD180B — Continued
External Static Pressure (Inches of Water)
1.10 1.20 1.30 1.40 1.50 1.60 1.70 1.80 1.90 2.00
CFM RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP
5 HP Oversized Motor & Drive 5 HP Oversized Motor & Field Supplied High Static Drive (2)
4800 954 3.41 976 3.60 998 3.78 1020 3.98 1041 4.17 1062 4.38 1082 4.57 1102 4.76 1120 4.95 1138 5.14
5400 1014 4.25 1035 4.46 1055 4.66 1074 4.87 1095 5.08 1114 5.30 1133 5.51 1153 5.73 1171 5.94 1190 6.16
6000 1077 5.26 1097 5.48 1116 5.71 1134 5.93 1153 6.16 1171 6.38 1189 6.61 1207 6.85 1224 7.08 1242 7.31
6600 1143 6.43 1161 6.67 1180 6.92 1197 7.17 1215 7.41 1232 7.66 1249 7.91 1266 8.15 1282 8.41 — —
7200 1207 7.74 1227 8.04 1245 8.32 1262 8.59 — — — — — — — — — — — —
7.5 HP Oversized Motor with Field Supplied High Static Drive (3) (4)
Table PD-7 — Evaporator Fan Performance — 15 Ton — WCD180B
External Static Pressure (Inches of Water)
.10 .20 .30 .40 .50 .60 .70 .80 .90 1.00
CFM RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP
3 HP Standard Motor Drive
4800 691 1.64 723 1.81 751 1.97 778 2.13 808 2.32 836 2.51 861 2.68 885 2.86 909 3.04 931 3.22
5400 769 2.29 799 2.48 826 2.66 850 2.83 874 3.02 900 3.23 926 3.45 950 3.65 972 3.86 993 4.05
6000 848 3.09 875 3.30 901 3.51 924 3.71 946 3.90 967 4.09 991 4.33 1014 4.57 1037 4.81 1058 5.04
6600 928 4.06 953 4.30 977 4.53 999 4.76 1020 4.97 1039 5.18 1059 5.39 1080 5.64 1101 5.90 1122 6.17
7200 1008 5.22 1031 5.48 1053 5.74 1075 5.99 1095 6.24 1113 6.46 1131 6.69 1149 6.93 1168 7.18 1188 7.46
5 HP Oversized Motor & Drive Field Supplied 7.5 HP Oversized Motor & Drive (3)
5 HP Oversized Motor & Field
Supplied High Static Drive (2) 3 HP Standard Motor & Field
Supplied High Static Drive (1) 3 HP Standard Motor & Field
Supplied High Static Drive (1)
3 HP Standard Motor & Field
Supplied High Static Drive (1) 7.5 HP Oversized Motor & Drive
Fan motor heat (MBH) = 3.15 x Fan BHP.
Data includes pressure drop due to wet coils and filters.
No accessories or options are included in pressure drop data.
Refer to Table PD-13 to determine additional static pressure drop due to other
options/accessories.
Notes:
1. Field Supplied Fan Sheave BK77(1"bore) required.
2. Field Supplied Motor Sheave 1VP50 (7/8" bore) required.
3. 7.5 hp motor kit BAYHSMT041 (208/460V), BAYHSMT042 (575V)
4. Field Supplied fan sheave BK115 (1" bore) required.
Factory supplied motors, in commercial equipment, are definite purpose
motors, specifically designed and tested to operate reliably and continuously at
all cataloged conditions, Using the full horsepower range of our fan motors as
shown in our tabulated data will not result in nuisance tripping or premature
motor failure. Our product's warranty will not be affected.
3 HP Standard Motor & Field
Supplied Low Static Drive (1) 5 HP Oversized Motor & Field
Supplied High Static Drive (3)
7.5 HP Oversized Motor & Drive (4)
Fan motor heat (MBH) = 3.15 x Fan BHP.
Data includes pressure drop due to wet coils and filters.
No accessories or options are included in pressure drop data.
Refer to Table PD-13 to determine additional static pressure drop due to other options/
accessories.
Notes:
1. Field Supplied Fan Sheave BK95 (1" bore) required
2. Field Supplied Fan Sheave BK77 (1" bore) required. 3. Field Supplied Motor Sheave 1VP50 (7/8" bore) required.
4. 7.5 hp motor kit BAYHSMT041 (208/460V), BAYHSMT042 (575V)
5. Field Supplied fan sheave BK115 (1" bore) required.
Factory supplied motors, in commercial equipment, are definite purpose motors,
specifically designed and tested to operate reliably and continuously at all cataloged
conditions, Using the full horsepower range of our fan motors as shown in our
tabulated data will not result in nuisance tripping or premature motor failure. Our
product's warranty will not be affected.
