20 PKGP-PRC001-EN
Performance
Data
(12½ - 20 Tons)
* Indicates both downflow and horizontal units.
Table PD-10 — Standard Motor & Drive/Fan Speed (RPM)
Unit 6 Turns 5 Turns 4 Turns 3 Turns 2 Turns 1 Turn
Tons Model No. Open Open Open Open Open Open Closed
12½ WC * 150B 640 680 720 760 800 840 N/A
15 WC * 180B 679 721 764 806 849 891 N/A
20 WC * 240B 615 659 703 747 791 835 N/A
Factory set at 3 turns open.
Table PD-11 — Standard Motor With High Static Drive Fan Speed (RPM)
Unit 6 Turns 5 Turns 4 Turns 3 Turns 2 Turns 1 Turn
Tons Model No. Open Open Open Open Open Open Closed
12½ WC * 150B 807 857 908 958 1009 1059 N/A
20 WC * 240B 835 879 923 967 1011 1055 N/A
Table PD-12 — Oversized Motor & Drive/Fan Speed (RPM)
Unit 6 Turns 5 Turns 4 Turns 3 Turns 2 Turns 1 Turn
Tons Model No. Open Open Open Open Open Open Closed
12½ WC * 150B 869 923 978 1032 1087 1141 N/A
15 1 WC * 180B 806 856 907 957 1008 1058 N/A
15 2 WC*180b 949 1008 1068 1127 1187 1246 N/A
20 WC * 240B 816 853 890 928 965 1002 N/A
Notes:
1. 5 hp oversized motor/drive.
2. 7.5 hp overized motor/drive.
