General Unit Requirements

The checklist listed below is a summary of the steps re-
quired to successfully install a Commercial rooftop unit.
This checklist is intended to acquaint the installing person-
nel with what is required in the installation process. It does
not replace the detailed instructions called out in the appli-
cable sections of this manual.

[ ] Check the unit for shipping damage and material short-

age; file a freight claim and notify Trane office.

[ ] Verify that the installation location of the unit will provide

the required clearance for proper operation.

[ ] Assemble and install the roof curb. Refer to the current

edition of SAHF-IN-5 for 20 through 75 Ton units or
SXHG-IN-2 for 90 through 130 Ton units.

[ ] Fabricate and install ductwork; secure ductwork to curb.

[ ] Install pitch pocket for power supply through building

roof. (If applicable)

[ ] Rigging the unit.

[ ] Set the unit onto the curb; check for levelness.

[ ] Ensure unit-to-curb seal is tight and without buckles or

cracks.

[ ] Install and connect condensate drain lines to each

evaporator drain connection.

[ ] Remove the shipping hardware from each compressor

assembly.

[ ] Remove the shipping hold-down bolts and shipping chan-

nels from the supply and exhaust fans ordered with rub-
ber or spring isolators.

[ ] Check all optional supply and exhaust fan spring isola-

tors for proper adjustment.

[ ] Verify that all plastic coverings are removed from the

compressors.

[ ] Verify all discharge and liquid line service valves (one per

circuit) are back seated.

Main Electrical Power Requirements

[ ] Verify that the power supply complies with the unit name-

plate specifications.

[ ] Inspect all control panel components; tighten any loose

connections.

[ ] Connect properly sized and protected power supply wir-

ing to a field-supplied/installed disconnect and unit

[ ] Properly ground the unit.

Note: All field-installed wiring must comply with
NEC and applicable local codes.

Field Installed Control Wiring

[ ] Complete the field wiring connections for the constant

volume controls as applicable. Refer to "Field Installed
Control Wiring" for guidelines.

[ ] Complete the field wiring connections for the variable air

volume controls as applicable. Refer to "Field Installed
Control Wiring" for guidelines.

Note: All field-installed wiring must comply with
NEC and applicable local codes.

Requirements for Electric Heat Units

All SEHF Units (380 minimum voltage) & SEHG units.

[ ] Verify that the power supply complies with the electric

heater specifications on the unit and heater nameplate.

[ ] Inspect the heater junction box and control panel; tighten

any loose connections.

[ ] Check electric heat circuits for continuity.

SEHF Units w/200V or 230V Electric Heat:
(Requires Separate Power Supply to Heater)

[ ] Connect properly sized and protected power supply wir-

ing for the electric heat from a dedicated, field- supplied/
installed disconnect to terminal block 4TB2, or to an op-
tional unit mounted disconnect switch 4S15.

Requirements for Gas Heat

[ ] Gas supply line properly sized and connected to the unit

gas train.

[ ] All gas piping joints properly sealed.

[ ] Drip leg Installed in the gas piping near the unit.

[ ] Gas piping leak checked with a soap solution. If piping

connections to the unit are complete, do not pressurize
piping in excess of 0.50 psig or 14 inches w.c. to prevent
component failure.

[ ] Main supply gas pressure adequate.

[ ] Flue Tubes clear of any obstructions.

[ ] Factory-supplied flue assembly installed on the unit.

[ ] Connect the 3/4" CPVC furnace drain stubout to a proper

condensate drain.

Requirements for Hot Water Heat (SLH_)

[ ] Route properly sized water piping through the base of the

unit into the heating section.

[ ] Install the factory-supplied, 3-way modulating valve.

[ ] Complete the valve actuator wiring.
