Trane INTELLIPAK ™ ™ ™ ™ ™ Commercial Single-Zone Rooftop Air Conditioners with CV or VAV Control User Manual
Page 22

21
Units with
Units
Units
100%
without
with Supply &
Exhaust Fan
Exhaust Fan Exhaust VFD
Unit
Unit
Dim.
Dim.
Dim.
Dim.
Dim.
Dim.
Model Size
A
B
A
B
A
B
SAHF C20
12' 6"
3' 8"
13' 5" 3' 10" 11' 10" 3' 9"
C25
12' 9"
3' 8"
13' 7" 3' 10" 12' 0"
3' 9"
C30
12' 5"
3' 8"
13' 3" 3' 10" 11' 9"
3' 9"
C40
15' 7"
3' 10" 16' 9"
4' 0" 14' 10" 3' 11"
C50
16' 7"
3' 10" 17' 9"
4' 0"
15' 8"
3' 11"
C55
16' 10" 3' 10" 18' 1"
4' 0"
16' 0"
3' 11"
C60
15' 7"
4' 7" 16' 11" 4' 10" 14' 10" 4' 8"
C70
15' 10"
4' 8"
17' 1" 4' 10" 15' 2"
4' 9"
C75
15' 11"
4' 8"
17' 2" 4' 10" 15' 2"
4' 9"
SEHF
C20
13' 8"
3' 8"
14' 7" 3' 10" 12' 11" 3' 9"
SLHF
C25
13' 10"
3' 7"
14' 9"
3' 9"
13' 1"
3' 9"
SSHF C30
13' 6"
3' 8"
14' 5"
3' 9" 12' 10" 3' 9"
SXHF C40
17' 10" 3' 10" 18' 3" 3' 11" 16' 3"
3' 11"
C50
18' 1"
3' 10" 19' 4"
4' 0"
17' 2"
3' 11"
C55
18' 5"
3' 11" 19' 8"
4' 0"
17' 8"
3' 10"
C60
17' 0"
4' 7"
18' 6"
4' 9"
16' 3"
4' 8"
C70
17' 5"
4' 8"
18' 9" 4' 10" 16' 7"
4' 9"
C75
17' 5"
4' 8"
18' 9" 4' 10" 16' 7"
4' 9"
SFHF
C20
13' 10"
3' 8"
14' 8" 3' 10" 13' 1"
3' 9"
C25
14' 0"
3' 7" 14' 10" 3' 9"
13' 3"
3' 8"
C30
13' 8"
3' 8"
14' 6"
3' 9"
13' 0"
3' 9"
C40
17' 3"
3' 9"
18' 5" 3' 11" 16' 6"
3' 10"
C50
18' 2"
3' 10" 19' 4"
4' 0"
17' 4"
3' 11"
C55
18' 6"
3' 10" 19' 8" 3' 11" 17' 8"
3' 10"
C60
17' 3"
4' 6"
18' 7"
4' 9"
16' 5"
4' 7"
C70
17' 6"
4' 7"
18' 9" 4' 10" 16' 9"
4' 8"
C75
17' 6"
4' 7"
18' 9" 4' 10" 16' 9"
4' 8"
SXHG,
SEHG, C90
18' 9"
5’ 10" 20' 4"
6' 2"
17' 9"
5' 10"
SLHG, D11
19' 1"
5’ 11" 20’ 7"
6' 2"
18' 1"
6' 0"
SSHG
SFHG C90
18' 11"
6' 0"
20' 6"
6' 3" 17' 10" 5' 11"
D11
19' 3"
6' 0"
20' 9"
6' 4"
18' 4"
6' 7"
SXHG,
SEHG, D12
19' 2"
5' 10" 20' 8"
6' 2"
18' 1"
6' 0"
SLHG, D13
19' 5"
5' 10" 20' 11" 6' 2"
18' 6"
6' 0"
SSHG
SFHG D12
19' 4"
6' 0"
20' 9"
6' 3"
18' 3"
6' 1"
D13
19' 6"
6' 0" 21' 10" 6' 3"
18' 8"
6' 0"
Note:
1. Dimensions shown for the center-of-gravity are
approximate and are based on a unit equipped with:
Standard coils, 100% economizer, throwaway filters,
hi-efficiency motors, inlet guide vanes, 460 volt XL start,
high capacity heat (as applicable).
Figure 3-3
Center-of-Gravity Data (See Note 1)
