Specifications
Note
The specifications and design of this product are subject to change without notice.
General
System DVD-Video, DVD-RW/-R, DVD+RW/+R, CD-DA, CD-RW/-R,
Video Cassette Tape
VCR video heads Four heads
Power requirements 220–240 V ± 10%, 50 Hz ± 0.5%
Power consumption 35 W (standby: 5.0 W)
Weight 4.3 kg
Dimensions (width x height x depth) 435 x 99.5 x 260 mm
Operating temperature 5°C to 40°C
Operating humidity Less than 80% (no condensation)
TV format PAL-I
Recording
Recording format Video Recording (VR) format (DVD-RW only),
Video format (DVD-RW, DVD-R)
+VR format (DVD+RW, DVD+R)
Recordable discs DVD-ReWritable, DVD-Recordable, DVD+ReWritable,
DVD+Recordable
Video recording format
Sampling frequency
Compression format
13.5 MHz
MPEG
Audio recording format
Sampling frequency
Compression format
48 kHz
Dolby Digital
Tuner
Receivable channels IRA-E69
Input/Output
Front Panel : (AV3)
Video input
Input level One RCA connector
1Vp-p (75
Ω)
S-Video input
Input level One Mini DIN 4-pin jack
Y (Iuminance) 1Vp-p (75
Ω)
C (colour) 300mVp-p (75 Ω)
Audio input
Input level Two RCA connectors
2Vrms (input impedance: more than 10k
Ω)
Rear Panel :
VHF/UHF antenna input/output terminal VHF/UHF set 75 Ω
Audio input /output Two 21-pin scart sockets (AV1, AV2)
Video input /output
Input /output level Two 21-pin scart sockets (AV1, AV2)
1Vp-p (75
Ω) each
S-Video output
Input /output level One Mini DIN 4-pin jacks
Y (Iuminance) 1Vp-p (75
Ω)
C (colour) 300mVp-p (75 Ω)
Component video output
Output level Three RCA connectors
Y: 1.0Vp-p (75
Ω)
P B /C B , P R /C R : 0.7Vp-p (75 Ω) each
Audio output
Output level Two RCA connectors
2Vrms (output impedance: 680
Ω)
Digital audio output
Output level One Coaxial pin jack
500mVp-p (75
Ω)
