4.8
NAND Flash Control Register (NANDFCR)
The NAND Flash control register (NANDFCR) is shown in
and described in
.
Figure 27. NAND Flash Control Register (NANDFCR)
31
16
Reserved
R-0
15
12
11
10
9
8
Reserved
CS5ECC
CS4ECC
CS3ECC
CS2ECC
R-0
R/W-0
R/W-0
R/W-0
R/W-0
7
4
3
2
1
0
Reserved
CS5NAND
CS4NAND
CS3NAND
CS2NAND
R-0
R/W-0
R/W-0
R/W-0
R/W-0
LEGEND: R/W = Read/Write; R = Read only; -n = value after reset
Table 40. NAND Flash Control Register (NANDFCR) Field Descriptions
Bit
Field
Value
Description
31-12
Reserved
0
Reserved
11
CS5ECC
NAND Flash ECC start for chip select 5.
0
Do not start ECC calculation.
1
Start ECC calculation on data for NAND Flash on EM_CS5.
10
CS4ECC
NAND Flash ECC start for chip select 4.
0
Do not start ECC calculation.
1
Start ECC calculation on data for NAND Flash on EM_CS4.
9
CS3ECC
NAND Flash ECC start for chip select 3.
0
Do not start ECC calculation.
1
Start ECC calculation on data for NAND Flash on EM_CS3.
8
CS2ECC
NAND Flash ECC start for chip select 2.
0
Do not start ECC calculation.
1
Start ECC calculation on data for NAND Flash on EM_CS2.
7-4
Reserved
0
Reserved
3
CS5NAND
NAND Flash mode for chip select 5.
0
Not using NAND Flash.
1
Using NAND Flash on EM_CS5.
2
CS4NAND
NAND Flash mode for chip select 4.
0
Not using NAND Flash.
1
Using NAND Flash on EM_CS4.
1
CS3NAND
NAND Flash mode for chip select 3.
0
Not using NAND Flash.
1
Using NAND Flash on EM_CS3.
0
CS2NAND
NAND Flash mode for chip select 2.
0
Not using NAND Flash.
1
Using NAND Flash on EM_CS2.
