Use Cases www.ti.com
Inserting these values into the equations defined above allows you to determine the values for SETUP,
STROBE, HOLD, and TA. For a read:
Therefore with a 10 nS margin added in, R_SETUP ≥ 1.0, R_STROBE ≥ 6.5, and R_HOLD ≥ 0.
After solving for R_HOLD, TA may be calculated:
Adding a 10 ns margin, TA ≥ 2.
For a write:
Therefore with a 10 nS margin added in, W_SETUP ≥ 0, W_STROBE ≥ 6, and W_HOLD ≥ 1.
