Meeting AC Timing Requirements for NAND Flash
When configuring the EMIF to interface to NAND Flash, you must consider the AC timing requirements of
the NAND Flash as well as the AC timing requirements of the EMIF. These can be found in the data sheet
for each respective device. The read and write asynchronous cycles are programmed separately in the
asynchronous configuration register (ACFGn).
As described in
, a NAND Flash access cycle is composed of a command, address, and data
phases. The EMIF will not automatically generate these three phases to complete a NAND access with
one transfer request. To complete a NAND access cycle, multiple single asynchronous access cycles
must be completed by the EMIF. The command and address phases of a NAND Flash access cycle are
asynchronous writes performed by the EMIF where as the data phase can be either an asynchronous
write or a read depending on whether the NAND Flash is being programmed or read.
Therefore, to determine the required EMIF configuration to interface to the NAND Flash for a read
operation,
and
list the AC timing parameters that must be considered.
Table 25. EMIF Read Timing Requirements
Parameter
Description
t
SU
Data Setup time, data valid before EM_OE high
t
H
Data Hold time, data valid after EM_OE high
Table 26. NAND Flash Read Timing Requirements
Parameter
Description
t
RP
Read Pulse width
t
REA
Read Enable Access time
t
CEA
Chip Enable low to output valid
t
CHZ
Chip Enable high to output High-impedance
t
RC
Read Cycle time
t
RHZ
Read enable high to output High-impedance
t
CLR
Command Latch low to Read enable low
shows an asynchronous read access and describes how the EMIF and NAND Flash AC timing
requirements work together to define the values for R_SETUP, R_STROBE, and R_HOLD.
